Products Details
Type | Blade | Specification | Shim | Screw | Wrench | Lateral screw |
| 6Dmin | d | f | L | L1 | H | α° | | | | |
SNR/L0007J08 | 08NR/L□□ | 9 | 7 | 5.3 | 110 | 15 | 6.4 | 15° | | M2.2×6 | T6 | M3×8C |
SNR/L0008K08 | 11 | 8 | 6.6 | 125 | 15 | 7 |
SNR/L0008K08 | 11NR/L□□ | 11 | 8 | 6 | 125 | 15 | 7 | | M2.5×7 | T8 |
SNR/L0010K10 | 12 | 10 | 7.2 | 125 | 18 | 9 |
SNR/L0012M11 | 15 | 12 | 8.7 | 150 | 18 | 11 |
SNR/L0013N16 | 16NR/L□□ | 17 | 13 | 10.2 | 160 | 25 | 12 | | M3.5×10 | T15 |
SNR/L0016Q16 | 19 | 16 | 11.5 | 180 | 25 | 14.6 |
SNR/L0020R16 | 24 | 20 | 13.5 | 200 | 28 | 18.4 |
SNR/L0025S16 | 29 | 25 | 16 | 250 | 32 | 23.4 | STM1603R/STM1603L | M3.5×12 | T15 |
SNR/L0032T16 | 36 | 32 | 19.5 | 300 | 38 | 30 |
SNR/L0040T16 | 44 | 40 | 23.5 | 300 | 42 | 38 |
SNR/L0050U16 | 54 | 50 | 28.5 | 350 | 50 | 48 |
SNR/L0020R22 | 22NR/L□□ | 24 | 20 | 13.5 | 200 | 32 | 18.4 | STM22T3R/STM22T3L | M4.5×14 | T20 T15 |
SNR/L0025S22 | 31 | 25 | 18 | 250 | 32 | 23.4 |
SNR/L0032T22 | 38 | 32 | 21.5 | 300 | 38 | 30 |
SNR/L0040T22 | 46 | 40 | 25.5 | 300 | 42 | 38 |
SNR/L0050U22 | 56 | 50 | 30.5 | 350 | 50 | 48 |
HSNR/L0010K10 | 11NR/L□□ | 12 | 10 | 7.2 | 125 | 18 | 9 | | M2.5×6 | T8 |
HSNR/L0012M11 | 15 | 12 | 8.7 | 150 | 18 | 11 |
HSNR/L0016Q16 | 16NR/L□□ | 19 | 16 | 11.5 | 180 | 25 | 14.6 | | M3.5×10 | T15 |
HSNR/L0020R16 | 24 | 20 | 13.5 | 200 | 28 | 18.4 |
HSNR/L0025S16 | 29 | 25 | 16 | 250 | 32 | 23.4 | STM1603/STM1603L | M3.5×12 | T15 |
HSNR/L0032T16 | 36 | 32 | 19.5 | 300 | 38 | 30 |
HSNR/L0040T16 | 44 | 40 | 23.5 | 300 | 42 | 38 |
HSNR/L0050U16 | 54 | 50 | 28.5 | 350 | 50 | 48 |
HSNR/L0025S22 | 22NR/L□□ | 31 | 25 | 18 | 250 | 32 | 23.4 | STM22T3/STM22T3L | M4.5×12 | T20 T15 |
HSNR/L0032T22 | 38 | 32 | 21.5 | 300 | 38 | 30 |
HSNR/L0040T22 | 46 | 40 | 25.5 | 300 | 42 | 38 |
HSNR/L0050U22 | 56 | 50 | 30.5 | 350 | 50 | 48 | | |
