·Quenching and hardening, not easy to deform ·Imported raw materials to create high-quality matrix, quality assurance, and prolong life ·Using high-quality coating, the processing is smoother, which effectively enhances the overall performance of the tool holder and prolongs the service life

Designation	Dimensions(mm)				Teeth	Applicable inserts	Screw	Wrench
	D	d	L1	L
BAP 300R C10-10-100	10	10	30	100	1	APMT1135PDER	M2.5×6	T8
BAP 300R C10-10-120	10	10	30	120	1		M2.5×6	T8
BAP 300R C12-12-130	12	12	30	130	1		M2.5×6	T8
BAP 300R C12-13-130	13	12	30	130	1		M2.5×6	T8
BAP 300R C15-16-150	16	15	40	150	2		M2.5×6	T8
BAP 300R C16-16-120	16	16	40	120	2		M2.5×6	T8
BAP 300R C16-16-150	16	16	50	150	2		M2.5×6	T8
BAP 300R C16-16-200	16	16	60	200	2		M2.5×6	T8
BAP 300R C16-17-120	17	16	40	120	2		M2.5×6	T8
BAP 300R C16-17-150	17	16	40	150	2		M2.5×6	T8
BAP 300R C16-17-200	17	16	40	200	2		M2.5×6	T8
BAP 300R C19-20-150	20	19	40	150	2		M2.5×6	T8
BAP 300R C19-20-200	20	19	40	200	2		M2.5×6	T8
BAP 300R C20-20-120	20	20	40	120	2		M2.5×6	T8
BAP 300R C20-20-150	20	20	50	150	2		M2.5×6	T8
BAP 300R C20-20-200	20	20	60	200	2		M2.5×6	T8
BAP 300R C20-21-150	21	20	50	150	2		M2.5×6	T8
BAP 300R C20-21-200	21	20	60	200	2		M2.5×6	T8
BAP 300R C25-25-150	25	25	50	150	3		M2.5×6	T8
BAP 300R C25-25-20	25	25	60	200	3		M2.5×6	T8
